Kalmar Forklift Error Codes Engine. DTC
Reachstackers DRT 400 450,DRF 450, DRF 420-450L
When contacting engine suppliers, use the supplier code.
• Display indicates error code as shown in the machine, in
accordance with SAE J1939 in SPN/FMI
• The supplier code indicates the error code in accordance with the
engine manufacturer's specification.
Table Specifications FMI
|
FMI |
Description |
SAE-text |
|
0 |
Too high value. |
Data valid, but higher than normal operating range. |
|
1 |
Too low value. |
Data valid, but lower than normal operating range. |
|
2 |
Incorrect data. |
Intermittent or incorrect data. |
|
3 |
Electrical problem. |
Abnormally high voltage or short-circuit to higher voltage. |
|
4 |
Electrical problem. |
Abnormally low voltage or short-circuit to lower voltage. |
|
5 |
Electrical problem. |
Abnormally low current or open circuit. |
|
6 |
Electrical problem. |
Abnormally high current or short-circuit to ground. |
|
7 |
Mechanical problem. |
Incorrect response from mechanical system. |
|
8 |
Mechanical problem or electrical problem. |
Abnormal frequency. |
|
9 |
Communication error. |
Abnormal update rate. |
|
10 |
Mechanical problem or electrical problem. |
Abnormally wide variations. |
|
11 |
Unknown malfunction. |
Non-identifiable malfunction. |
|
12 |
Component error. |
Incorrect unit or component. |
|
13 |
Incorrect calibration. |
Values outside calibration values. |
|
14 |
Unknown malfunction. |
Special instructions. |
|
15 |
Unknown malfunction. |
Reserved for future use. |
Error codes engine (engine alternative Yuchai YC6M360-30)
|
Display |
Sup- plier code |
Description |
Limitation |
Action |
|
95/3 |
P1015 |
Sensor pressure fuel filter, signal high. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
95/4 |
P1016 |
Sensor pressure fuel filter, signal low. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
95/7 |
P1018 |
Fuel filter clogged. |
No limitation. |
Change the fuel filter. |
|
97/3 |
P2267 |
Water-in-fuel sensor (B760), short circuit to voltage. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
97/4 |
P2266 |
Water-in-fuel sensor (B760), short circuit to ground. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
97/11 |
P2269 |
Water in fuel. |
No limitation. |
Change the fuel prefilter. |
|
98/2 |
P250B |
Sensor engine oil level, unreasonable signal. |
No limitation. |
Check the cable harness at the control unit. |
|
98/3 |
P250D |
Sensor engine oil level, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
98/4 |
P250C |
Sensor engine oil level, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
98/12 |
P250A |
Sensor engine oil level, incorrect signal via CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
100/2 |
P0521 |
Sensor engine oil pressure, unreasonable signal. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. Check the oil level in the engine. |
|
100/3 |
P0523 |
Sensor engine oil pressure, short circuit to voltage. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
100/4 |
P0522 |
Sensor engine oil pressure, short circuit to ground. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
100/12 |
P0520 |
Sensor engine oil pressure, incorrect signal via CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
100/17 |
P0524 |
Low engine oil pressure. |
Reduced engine power. |
Check the oil level in the engine. Change oil filter. Check the system pressure valves and the safety valve in the lubrication system. Check the sensor. |
|
102/2 |
P0236 |
Sensor boost pressure and sensor air pressure, unreasonable signal combination. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensors. |
|
102/3 |
P0238 |
Sensor boost pressure, short circuit to voltage. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
102/4 |
P0237 |
Sensor boost pressure, short circuit to ground. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
102/12 |
P0235 |
Sensor boost pressure, incorrect signal via CAN bus. |
Reduced engine power. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
105/3 |
P0098 |
Sensor intake temperature, incorrect signal. Short circuit to voltage. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
105/4 |
P0097 |
Sensor intake temperature, short circuit to ground. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
105/12 |
P0099 |
Sensor intake temperature, incorrect signal via CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
108/2 |
P2227 |
Sensor air pressure and sensor boost pressure, unreasonable signal combination. |
Reduced engine power.
|
Check the cable harness between control unit and sensor. Check the sensors. |
|
108/3 |
P2229 |
Sensor air pressure, short circuit to voltage. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
108/4 |
P2228 |
Sensor air pressure, short circuit to ground. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
108/12 |
P0000 |
Sensor air pressure, incorrect signal via CAN bus. |
Reduced engine power. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
110/2 |
P0116 |
Coolant temperature sensor, the temperature is unreasonable in relation to the oil temperature. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
110/3 |
P0118 |
Sensor coolant temperature, short circuit to voltage. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
Dis play |
Sup- plier code |
Description |
Limitation |
Action |
|
110/4 |
P0117 |
Sensor coolant temperature, short circuit to ground. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
110/12 |
P0115 |
Sensor coolant temperature, incorrect signal via CAN bus. |
Reduced engine power. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
110/15 |
P0217 |
Coolant temperature too high |
No limitation. |
Check the coolant level. Check that radiator is clean. Check the thermostat. Check the cap on the expansion tank. Check if there is air in coolant system. Check the cable harness between control unit and sensor. Check the sensor. |
|
111/2 |
P2557 |
Sensor coolant level, unreasonable signal combination. |
No limitation. |
Check the cable harness at the control unit. |
|
111/3 |
P2559 |
Sensor coolant level, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
111/4 |
P2558 |
Sensor coolant level, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
111/12 |
P2556 |
Sensor coolant level, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
132/3 |
P0101 |
Mass air flow sensor, signal deviation too high. |
No limitation. |
Check the cable harness at the control unit. |
|
132/3 |
P0103 |
Mass air flow sensor, air flow too high. |
No limitation. |
Check the cable harness at the control unit. |
|
132/4 |
P0101 |
Mass air flow sensor, signal deviation too low. |
No limitation. |
Check the cable harness at the control unit. |
|
132/4 |
P0102 |
Mass air flow sensor, air flow too low. |
No limitation. |
Check the cable harness at the control unit. |
|
157/3 |
P0193 |
Sensor fuel pressure, short circuit to voltage. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
157/4 |
P0192 |
Sensor fuel pressure, short circuit to ground. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
157/15 |
P0191 |
Sensor fuel pressure, signal deviation too high. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
157/17 |
P0191 |
Sensor fuel pressure, signal deviation too high. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
158/12 |
P2533 |
Ignition key lock, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
168/3 |
P0563 |
High battery voltage. |
No limitation. |
Check the voltage feed. If equipment for assisted start is connected, disconnect it. |
|
168/4 |
P0562 |
Low battery voltage. |
The engine may be difficult to start. |
Check and charge the batteries. Check the cable harness to the control unit. Check alternator, battery and cable harness between battery and alternator. |
|
171/3 |
P0073 |
Sensor outdoor temperature, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
171/4 |
P0072 |
Sensor outdoor temperature, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
171/12 |
P0071 |
Sensor outdoor temperature, incorrect signal via CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
172/3 |
P0113 |
Sensor intake temperature, high signal. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
172/4 |
P0112 |
Sensor intake temperature, low signal. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
174/3 |
P0183 |
Sensor fuel temperature, short circuit to voltage. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
174/4 |
P0182 |
Sensor fuel temperature, short circuit to ground. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
175/3 |
P0198 |
Sensor engine oil temperature, short circuit to voltage. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
175/4 |
P0197 |
Sensor engine oil temperature, short circuit to ground. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
175/12 |
P0195 |
Sensor engine oil temperature, incorrect signal via CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
175/17 |
P0196 |
High oil temperature. |
No limitation. |
Check the oil level. Check coolant temperature and level. |
|
190/7 |
P0016 |
Sensor camshaft and sensor crankshaft, unreasonable signal combination. |
No limitation. |
Check the cable harness between control unit and sensors. Check the sensors. |
|
190/11 |
P0336 |
Sensor rotation speed crankshaft, irregular signal. |
The engine is extremely difficult to start and runs unevenly or stops.Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor.
|
|
190/12 |
P0008 |
Sensor camshaft rotation speed, signal error. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
190/12 |
P0335 |
Sensor rotation speed crankshaft, no signal. |
The engine is extremely difficult to start and runs unevenly or stops.Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
520/11 |
UD13A |
CAN bus, communication error. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
520/12 |
UD13B |
CAN bus, communication error. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
533/15 |
P0219 |
Engine speed too high. |
No limitation. |
Check the fuel pressure. Check the cable harness between control unit and sensors. Check sensor camshaft rotation speed and sensor crankshaft. |
|
596/2 |
P0564 |
Cruise control input, unreasonable signal. |
No limitation. |
Check the cable harness at the control unit. |
|
597/2 |
P0504 |
The signal from the brake pedal does not correspond with the accelerator pedal. |
No limitation. |
Check the cable harness at the control unit. |
|
597/12 |
P0571 |
Brake pedal, incorrect signal via CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
598/2 |
P0704 |
Sensor clutch, unreasonable signal. |
No limitation. |
Check the cable harness at the control unit. |
|
Dis play |
Sup- plier code |
Description |
Limitation |
Action |
|
598/12 |
P0704 |
Sensor clutch, incorrect signal via CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
624/2 |
P1626 |
Drive circuit lamp 1, overheating. |
No limitation. |
Check the cable harness at the control unit. |
|
624/2 |
P162A |
Drive circuit lamp 2, overheating. |
No limitation. |
Check the cable harness at the control unit. |
|
624/2 |
P162E |
Drive circuit lamp 3, overheated. |
No limitation. |
Check the cable harness at the control unit. |
|
624/2 |
P161C |
Drive circuit system lamp, overheated. |
No limitation. |
Check the cable harness at the control unit. |
|
624/2 |
P1632 |
Drive circuit warning lamp, overheated. |
No limitation. |
Check the cable harness at the control unit. |
|
624/3 |
P1623 |
Drive circuit lamp 1, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
624/3 |
P1627 |
Drive circuit lamp 2, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
624/3 |
P162B |
Drive circuit lamp 3, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
624/3 |
P1619 |
Drive circuit system lamp, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
624/3 |
P162F |
Drive circuit warning lamp, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
624/4 |
P1624 |
Drive circuit lamp 1, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
624/4 |
P1628 |
Drive circuit lamp 2, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
624/4 |
P162C |
Drive circuit lamp 3, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
624/4 |
P161A |
Drive circuit system lamp, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
624/4 |
P1630 |
Drive circuit warning lamp, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
624/12 |
P1625 |
Drive circuit lamp 1, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
624/12 |
P1629 |
Drive circuit lamp 2, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
624/12 |
P162D |
Drive circuit lamp 3, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
624/12 |
P161B |
Drive circuit system lamp, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
624/12 |
P1631 |
Drive circuit warning lamp, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
630/2 |
P062F |
Internal error engine control unit.
|
No limitation. |
Contact Yuchai service. |
|
630/4 |
P062F |
|||
|
630/12 |
P062F |
|||
|
636/11 |
P0341 |
Sensor rotation speed camshaft, irregular signal. |
The engine takes longer to start than normal. The engine is running normally once it has started. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
636/12 |
P0340 |
Sensor rotation speed camshaft, no signal. |
The engine takes longer to start than normal. The engine is running normally once it has started. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
639/12 |
UC029 |
CAN bus (A), electrical problem. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
645/3 |
P1511 |
Sensor machine speed, incorrect signal form. |
Engine speed is limited. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
645/4 |
P1512 |
Sensor machine speed, incorrect signal form. |
Engine speed is limited. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
645/12 |
P1513 |
Sensor machine speed, incorrect signal form. |
Engine speed is limited. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
651/3 |
P0262 |
Injector cylinder 1, short circuit to ground. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
651/8 |
P0261 |
Injector cylinder 1, short circuit between cables. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
651/11 |
P0263 |
Injector cylinder 1, installation-dependent error. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
651/11 |
P0263 |
Injector cylinder 1, indefinable error. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
651/11 |
P1213 |
Injector cylinder 1, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
651/11 |
P1214 |
Injector cylinder 1, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
651/11 |
P1215 |
Injector cylinder 1, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
651/12 |
P0201 |
Injector cylinder 1, open circuit. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
652/3 |
P0265 |
Injector cylinder 2, short circuit to ground. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
652/8 |
P0264 |
Injector cylinder 2, short circuit between cables. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
652/11 |
P0266 |
Injector cylinder 2, installation-dependent error. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
652/11 |
P0266 |
Injector cylinder 2, indefinable error. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
652/11 |
P1216 |
Injector cylinder 2, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
652/11 |
P1217 |
Injector cylinder 2, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
652/11 |
P1218 |
Injector cylinder 2, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
652/12 |
P0202 |
Injector cylinder 2, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
653/3 |
P0268 |
Injector cylinder 3, short circuit to ground. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
653/8 |
P0267 |
Injector cylinder 3, short circuit between cables. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
653/11 |
P0269 |
Injector cylinder 3, installation-dependent error. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
653/11 |
P0269 |
Injector cylinder 3, indefinable error. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
653/11 |
P1219 |
Injector cylinder 3, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
653/11 |
P121A |
Injector cylinder 3, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
653/11 |
P121B |
Injector cylinder 3, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
653/12 |
P0203 |
Injector cylinder 3, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
654/3 |
P0271 |
Injector cylinder 4, short circuit to ground. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
654/8 |
P0270 |
Injector cylinder 4, short circuit between cables. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
654/11 |
P0272 |
Injector cylinder 4, installation-dependent error. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
654/11 |
P0272 |
Injector cylinder 4, indefinable error. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
654/11 |
P121C |
Injector cylinder 4, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
654/11 |
P121D |
Injector cylinder 4, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
654/11 |
P121E |
Injector cylinder 4, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
654/12 |
P0204 |
Injector cylinder 4, open circuit. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
655/3 |
P0274 |
Injector cylinder 5, short circuit to ground. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
655/8 |
P0273 |
Injector cylinder 5, short circuit between cables. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
655/11 |
P0275 |
Injector cylinder 5, installation-dependent error. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
655/11 |
P0275 |
Injector cylinder 5, indefinable error. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
655/11 |
P121F |
Injector cylinder 5, installation-dependent error. |
No limitation.
|
Check the cable harness between control unit and injector. Check the injector. |
|
655/11 |
P1220 |
Injector cylinder 5, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
655/11 |
P1221 |
Injector cylinder 5, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
655/12 |
P0205 |
Injector cylinder 5, open circuit. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
656/3 |
P0277 |
Injector cylinder 6, short circuit to ground. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
656/8 |
P0276 |
Injector cylinder 6, short circuit between cables. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
656/11 |
P0278 |
Injector cylinder 6, installation-dependent error. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
656/11 |
P0278 |
Injector cylinder 6, indefinable error. |
Engine only runs on 3 cylinders and has reduced power. |
Check the cable harness between control unit and injector. Check the injector. |
|
656/11 |
P1222 |
Injector cylinder 6, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
656/11 |
P1223 |
Injector cylinder 6, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
656/11 |
P1224 |
Injector cylinder 6, installation-dependent error. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
656/12 |
P0206 |
Injector cylinder 6, open circuit. |
No limitation. |
Check the cable harness between control unit and injector. Check the injector. |
|
676/7 |
P0540 |
Relay, preheating (K312), signal error. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
677/3 |
P0617 P1638 |
Relay starter motor, short circuit to voltage or activated too long. |
No limitation. |
Check the cable harness at the control unit. |
|
677/4 |
P0616 P1639 |
Relay starter motor, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
677/5 |
P163A |
Relay starter motor, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
729/3 |
P0541 |
Relay preheating (K312), short circuit to ground. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
729/3 |
P0542 |
Relay preheating (K312), short circuit to voltage. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
729/3 |
P1020 |
Relay preheating (K312), high signal. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
729/4 |
P1021 |
Relay preheating (K312), active too short time. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
730/3 |
P1022 |
Relay preheating (K312), high signal. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
730/4 |
P1023 |
Relay preheating (K312), low signal. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
898/11 |
UD10E |
CAN bus, communication error. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
898/12 |
UD10F |
CAN bus, communication error. |
No limitation. |
|
|
|
|
|
|
|
|
970/3 |
P1617 |
Voltage error at shut-off, high battery voltage. |
Reduced engine power. |
Check the cable harness at the control unit. Check the component. |
|
970/4 |
P1618 |
Voltage error at shut-off, low battery voltage. |
Reduced engine power. |
Check the cable harness at the control unit. Check the component. |
|
970/12 |
P1616 |
Voltage error at shut-off, monitoring switched off. |
Reduced engine power. |
Check the cable harness at the control unit. Check the component. |
|
985/2 |
P2519 |
AC compressor, incorrect CAN message. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
985/12 |
P2519 |
AC compressor, incorrect CAN message. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
1041/7 |
P2530 |
Ignition key lock, incorrect signal. |
No limitation. |
Check the cable harness at the control unit. |
|
1041/8 |
P2530 |
Switch remote start engine, fixed in activated position. |
No limitation. |
Check the cable harness at the control unit. |
|
1071/2 |
P0483 |
Drive circuit cooling fan, overheated. |
No limitation. |
Check the cable harness at the control unit. |
|
1071/3 |
P0692 |
Drive circuit cooling fan, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
1071/3 |
P0694 |
Drive circuit cooling fan 2, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
1071/4 |
P0691 |
Drive circuit cooling fan, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
1071/4 |
P0693 |
Drive circuit cooling fan 2, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
1071/12 |
P0480 |
Drive circuit cooling fan, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
1072/3 |
P0080 |
Drive circuit brake valve, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
Dis play |
Sup- plier code |
Description |
Limitation |
Action |
|
1072/4 |
P0079 |
Drive circuit brake valve, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
1072/255 |
P1633 |
Drive circuit brake valve, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
1072/255 |
P1634 |
Drive circuit brake valve, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
1074/2 |
P0476 |
Drive circuit exhaust brake, overheated. |
No limitation. |
Check the cable harness at the control unit. |
|
1074/3 |
P0478 |
Drive circuit exhaust brake, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
1074/4 |
P0477 |
Drive circuit exhaust brake, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
1074/12 |
P0476 |
Drive circuit exhaust brake, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
1079/3 |
P0643 |
Voltage feed 1 sensor engine, high signal. |
Reduced engine power. |
Check the cable harness at the control unit. |
|
1079/4 |
P0642 |
Voltage feed 1 sensor engine, low signal. |
No limitation. |
Check the cable harness at the control unit. |
|
1080/3 |
P0653 |
Voltage feed 2 sensor engine, high signal. |
Reduced engine power. |
Check the cable harness at the control unit. |
|
1080/4 |
P0652 |
Voltage feed 2 sensor engine, low signal. |
No limitation. |
Check the cable harness at the control unit. |
|
1081/2 |
P1638 |
Drive circuit indicator light preheating, overheated. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
1081/3 |
P1635 |
Drive circuit indicator light preheating, short circuit to voltage. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
1081/4 |
P1636 |
Drive circuit indicator light preheating, short circuit to ground. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
1072/4 |
P0079 |
Drive circuit brake valve, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
1072/255 |
P1633 |
Drive circuit brake valve, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
1072/255 |
P1634 |
Drive circuit brake valve, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
1074/2 |
P0476 |
Drive circuit exhaust brake, overheated. |
No limitation. |
Check the cable harness at the control unit. |
|
1074/3 |
P0478 |
Drive circuit exhaust brake, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
1074/4 |
P0477 |
Drive circuit exhaust brake, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
1074/12 |
P0476 |
Drive circuit exhaust brake, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
1079/3 |
P0643 |
Voltage feed 1 sensor engine, high signal. |
Reduced engine power. |
Check the cable harness at the control unit. |
|
1079/4 |
P0642 |
Voltage feed 1 sensor engine, low signal. |
No limitation. |
Check the cable harness at the control unit. |
|
1080/3 |
P0653 |
Voltage feed 2 sensor engine, high signal. |
Reduced engine power. |
Check the cable harness at the control unit. |
|
1080/4 |
P0652 |
Voltage feed 2 sensor engine, low signal. |
No limitation. |
Check the cable harness at the control unit. |
|
1081/2 |
P1638 |
Drive circuit indicator light preheating, overheated. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
1081/3 |
P1635 |
Drive circuit indicator light preheating, short circuit to voltage. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
1081/4 |
P1636 |
Drive circuit indicator light preheating, short circuit to ground. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
1081/12 |
P1637 |
Drive circuit indicator light preheating, open circuit. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
1108/16 |
P1613 |
Engine speed too high. |
No limitation. |
Check the cable harness between control unit and the components. Check sensor camshaft rotation speed and sensor crankshaft. Check the fuel pressure. |
|
1192/2 |
P0046 |
Valve boost pressure control, overheating. |
No limitation. |
Check the cable harness at the control unit. |
|
1192/3 |
P0048 |
Valve boost pressure control, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
1192/3 |
P1000 |
Valve boost pressure control, signal too high. |
No limitation. |
Check the cable harness at the control unit. |
|
1192/4 |
P0047 |
Valve boost pressure control, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
1192/4 |
P1001 |
Valve boost pressure control, signal too low. |
No limitation. |
Check the cable harness at the control unit. |
|
1192/12 |
P0045 |
Valve boost pressure control, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
1192/12 |
P1002 |
Valve boost pressure control, incorrect signal. |
No limitation. |
Check the cable harness at the control unit. |
|
1213/2 |
P0650 |
Drive circuit warning lamp engine fault, overheated. |
No limitation. |
Check the cable harness between control unit and component. |
|
1213/3 |
P0650 |
Drive circuit warning lamp engine fault, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
1213/4 |
P0650 |
Drive circuit warning lamp engine fault, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
1213/12 |
P0650 |
Drive circuit warning lamp engine fault, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
Dis play |
Sup- plier code |
Description |
Limitation |
Action |
|
1231/12 |
UC038 |
CAN bus (C), electrical problem. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
1235/12 |
UC047 |
|||
|
1322/3 |
P0300 |
Misfiring on multiple cylinders. |
Reduced engine power. |
Contact Yuchai service. |
|
1323/3 |
P0301 |
Misfiring cylinder 1. |
Reduced engine power. |
Contact Yuchai service. |
|
1324/3 |
P0302 |
Misfiring cylinder 2. |
Reduced engine power. |
Contact Yuchai service. |
|
1325/3 |
P0303 |
Misfiring cylinder 3. |
Reduced engine power. |
Contact Yuchai service. |
|
1326/3 |
P0304 |
Misfiring cylinder 4. |
Reduced engine power. |
Contact Yuchai service. |
|
1327/3 |
P0305 |
Misfiring cylinder 5. |
Reduced engine power. |
Contact Yuchai service. |
|
1328/3 |
P0306 |
Misfiring cylinder 6. |
Reduced engine power. |
Contact Yuchai service. |
|
1351/2 |
P0645 |
Drive circuit AC compressor, overheated. |
No limitation. |
Check the cable harness at the control unit. |
|
1351/3 |
P0647 |
Drive circuit AC compressor, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
1351/4 |
P0646 |
Drive circuit AC compressor, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
1351/12 |
P0645 |
Drive circuit AC compressor, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
1485/3 |
P0687 |
Main relay 2, electrical problem. |
No limitation. |
Check the cable harness at the control unit. |
|
1485/4 |
P0686 |
Main relay 2, electrical problem. |
No limitation. |
Check the cable harness at the control unit. |
|
1624/3 |
P2158 |
Sensor machine speed, speed too high. |
No limitation. |
Check the cable harness at the control unit. |
|
1624/4 |
P2160 |
Sensor machine speed, speed too low. |
No limitation. |
Check the cable harness at the control unit. |
|
1624/12 |
P2157 |
Sensor machine speed, speed message via CAN bus incorrect. |
Engine speed is limited. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
1624/255 |
P2159 |
Sensor machine speed, unreasonable speed. |
Engine speed is limited. |
Check the cable harness at the control unit. |
|
1639/3 |
P0526 |
Sensor fan speed, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
1639/4 |
P0527 |
Sensor fan speed, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
2634/3 |
P160E |
Main relay, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
2634/4 |
P160F |
Main relay, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
2791/2 |
P0403 |
Drive circuit EGR valve, overheating. |
No limitation. |
Check the cable harness at the control unit. |
|
2791/3 |
P0490 |
Drive circuit EGR valve, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
2791/4 |
P0489 |
Drive circuit EGR valve, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
2791/5 |
P0404 |
Drive circuit EGR valve, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
520192/2 |
P063B |
Voltage feed speed sensor, incorrect signal (ADC). |
The engine is only running at idle. |
Check the cable harness between control unit and sensor. Check the sensor.
|
|
520192/3 |
P060B |
Voltage feed speed sensor, signal too high (ADC). |
The engine is only running at idle. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
520192/4 |
P061B |
Voltage feed speed sensor, signal too low (ADC). |
The engine is only running at idle. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
Dis play |
Sup- plier code |
Description |
Limitation |
Action |
|
520192/11 |
P062B |
Voltage feed speed sensor, incorrect test impulse(ADC). |
The engine is only running at idle. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
520193/3 |
P0103 |
Mass air flow sensor, air flow too high. |
No limitation. |
Check the cable harness at the control unit. |
|
520193/4 |
P0102 |
Mass air flow sensor, air flow too low, |
No limitation. |
Check the cable harness at the control unit. |
|
520194/2 |
P0649 |
Warning lamp speed limitation, overheated. |
No limitation. |
Check the cable harness at the control unit. |
|
520194/3 |
P0649 |
Warning lamp speed limitation, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
520194/4 |
P0649 |
Warning lamp speed limitation, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
520194/5 |
P0649 |
Warning lamp speed limitation, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
520195/15 |
P0402 |
EGR control, signal too high. |
No limitation. |
Check the cable harness at the control unit. |
|
520196/17 |
P0401 |
EGR control, signal too low. |
No limitation. |
Check the cable harness at the control unit. |
|
520197/3 |
P022C |
Bypass valve cold start, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
520197/4 |
P022B |
Bypass valve cold start, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
520197/12 |
P022A |
Bypass valve cold start, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
520198/2 |
P0116 |
Sensor coolant temperature, unreasonable signal. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor.
|
|
520198/2 |
P0116 |
Sensor coolant temperature, unreasonable signal. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
520199/2 |
P0856 |
DCS, unreasonable signal. |
No limitation. |
Check the cable harness at the control unit. |
|
520200/20 |
P161F |
Incorrect compression test. |
No limitation. |
contact Yuchai service. |
|
520201/3 |
P1505 |
Sensor outdoor temperature (BET), signal too high. |
No limitation. |
Check the cable harness at the control unit. |
|
520201/4 |
P1506 |
Sensor outdoor temperature (BET), signal too low. |
No limitation. |
Check the cable harness at the control unit. |
|
520202/3 |
P1507 |
Sensor outdoor temperature (ClgZn), signal too high. |
No limitation. |
Check the cable harness at the control unit. |
|
520202/4 |
P1508 |
Sensor outdoor temperature (ClgZn), signal too low. |
No limitation. |
Check the cable harness at the control unit. |
|
520203/3 |
P1509 |
Sensor intake temperature, signal too high. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
520203/4 |
P150A |
Sensor intake temperature, signal too low. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
520204/2 |
P1635 |
Switch exhaust brake, unreasonable signal. |
No limitation. |
Check the cable harness at the control unit. |
|
520205/3 |
P245D |
EGR valve, short circuit to voltage or overheated. |
No limitation. |
Check the cable harness at the control unit. |
|
520205/4 |
P245C |
EGR valve, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
520205/12 |
P245A |
EGR valve, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
520206/2 |
P0470 |
Exhaust back pressure sensor, unreasonable signal. |
No limitation. |
Check the cable harness at the control unit. |
|
520206/3 |
P0473 |
Sensor exhaust back pressure, signal too high. |
No limitation. |
Check the cable harness at the control unit. |
|
520206/4 |
P0472 |
Sensor exhaust back pressure, signal too low. |
No limitation. |
Check the cable harness at the control unit. |
|
520207/3 |
P1008 |
Relay heating coil fuel filter, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
Dis play |
Sup- plier code |
Description |
Limitation |
Action |
|
520207/4 |
P1009 |
Relay heating coil fuel filter, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
520208/2 |
P0409 |
Sensor airflow EGR valve, unreasonable signal. |
No limitation. |
Check the cable harness at the control unit. |
|
520208/3 |
P0406 |
Sensor airflow EGR valve, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
520208/4 |
P0405 |
Sensor airflow EGR valve, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
520208/12 |
P0409 |
Sensor airflow EGR valve, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
520209/2 |
P040B |
Sensor exhaust temperature, unreasonable signal. |
No limitation. |
Check the cable harness at the control unit. |
|
520209/3 |
P040D |
Sensor exhaust temperature, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
520209/4 |
P040C |
Sensor exhaust temperature, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
520209/12 |
P040A |
Sensor exhaust temperature, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
520210/3 or/255 |
UC158 |
Communication error, display. |
No limitation. |
Check the cable harness at the control unit. |
|
520211/12 |
P0000 |
Communication error, CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
520212/3 |
UD100 |
|||
|
520213/12 |
UC103 |
|||
|
520214/12 |
UC113 |
|||
|
520215/3 |
UD101 |
|||
|
520216/3 |
UC156 |
|||
|
520217/3 |
UD103 |
|||
|
520218/3 |
UD10C |
|||
|
520218/4 |
UD10D |
|||
|
520218/12 |
UD104 |
|||
|
520219/3 |
UD110 |
|||
|
520219/12 |
UD111 |
|||
|
520220/3 |
UD112 |
|||
|
520220/12 |
UD113 |
|||
|
520222/14 |
P0607 |
Internal error engine control unit. |
Engine switched off: engine cannot be started. Engine running: engine misfires. |
Contact Yuchai service.
|
|
520222/14 |
P0607 |
|||
|
520222/14 |
P0607 |
|||
|
520223/20 |
P160C |
Fuel injection, test mode. |
No limitation. |
Contact Yuchai service. |
|
520224/3 |
P150B |
Sensor air humidity, signal too high. |
No limitation. |
Check the cable harness at the control unit. |
|
520224/4 |
P150C |
Sensor air humidity, signal too low. |
No limitation. |
Check the cable harness at the control unit. |
|
520225/11 |
P1302 |
Injection error, software error. |
No limitation. |
Check the cable harness at the control unit. |
|
520225/15 |
P1301 |
Injection error, uneven amount of fuel between the cylinders. |
No limitation. |
Check the cable harness at the control unit. |
|
520225/16 |
P1300 |
Injection error, uneven output between the cylinders. |
No limitation. |
Check the cable harness at the control unit. |
|
520226/12 |
P1225 |
Pressure fault on multiple injectors. |
The engine is switched off. |
Check the injectors. |
|
520227/2 |
P154C |
Multi-function lever, unreasonable position. |
No limitation. |
Check the cable harness at the control unit. |
|
520227/3 |
P154A |
Multi-function lever, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
520227/4 |
23/04 |
Multi-function lever, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
520228/15 |
P1614 |
Sensor engine speed, unreasonable signal |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
520229/15 |
P2263 |
Intake pressure difference too high. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
520230/17 |
P2263 |
Intake pressure difference too low. |
No limitation. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
520231/2 |
P062A |
Feed pump, overheated. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
520231/3 |
P0629 |
Feed pump, short circuit to voltage. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
520231/4 |
P0628 |
Feed pump, short circuit to ground. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
520231/12 |
P0627 |
Feed pump, open circuit. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
520232/255 |
P1615 |
Test mode. |
No limitation. |
Contact Yuchai service. |
|
520233/20 |
P1621 |
Test mode. |
No limitation. |
Contact Yuchai service. |
|
520234/2 |
P0488 |
Throttle, overheated. |
No limitation. |
Check the cable harness at the control unit. |
|
520234/3 |
P2142 |
Throttle, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
520234/4 |
P2141 |
Throttle, short circuit to ground. |
The engine is running at idle. |
Check the cable harness at the control unit. |
|
520234/12 |
P0487 |
Throttle, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
520235/3 |
P1636 |
Reference voltage 12 V, signal too high. |
No limitation. |
Check the cable harness at the control unit. |
|
520235/4 |
P1637 |
Reference voltage 12 V, signal too high. |
No limitation. |
Check the cable harness at the control unit. |
|
520236/2 |
P1007 |
Software error engine control unit (FMTC). |
No limitation. |
Contact Yuchai service |
|
520237/3 |
UD114 |
Communication error, CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
520238/12 |
UD115 |
Communication error, CAN bus. |
No limitation. |
|
|
520239/2 |
P161E |
Internal error engine control unit. |
No limitation. |
Contact Yuchai service. |
|
520239/11 |
P161D |
Internal error engine control unit. |
No limitation. |
|
|
523218/12 |
UC104 |
Communication error, CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
523350/3 |
P1203 |
Injector bank 1, short circuit between cables. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523350/4 |
P1204 |
Injector bank 1, short circuit to ground. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523350/11 |
P1205 |
Injector bank 1, installation-dependent error. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523350/11 |
P1206 |
Injector bank 1, electrical problem. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523351/11 |
P1207 |
Injector bank 1, installation-dependent error. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523351/11 |
P1208 |
Injector bank 1, installation-dependent error. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523351/11 |
P120A |
Injector bank 1, installation-dependent error. |
The engine is only running on three cylinders.
|
Check the cable harness between control unit and the components. Check the injectors. |
|
523351/12 |
P1209 |
Injector bank 1, open circuit. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523352/3 |
P120B |
Injector bank 2, short circuit between cables. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523352/4 |
P120C |
Injector bank 2, short circuit to ground. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523352/11 |
P120D |
Injector bank 2, installation-dependent error. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523352/11 |
P120E |
Injector bank 2, electrical problem. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523353/11 |
P120F |
Injector bank 2, installation-dependent error. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523353/11 |
P1210 |
Injector bank 2, installation-dependent error. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523353/11 |
P1212 |
Injector bank 2, installation-dependent error. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523352/12 |
P1211 |
Injector bank 2, open circuit. |
The engine is only running on three cylinders. |
Check the cable harness between control unit and the components. Check the injectors. |
|
523354/2 |
P062B |
Internal error engine control unit. |
The engine is switched off. |
Contact Yuchai service.
|
|
523354/3 |
P062B |
|||
|
523354/4 |
P062B |
|||
|
523354/12 |
P062B |
|||
|
523355/2 |
P062B |
|||
|
523355/3 |
P062B |
|||
|
523355/4 |
P062B |
|||
|
523355/12 |
P062B |
|||
|
523420/2 |
P060C |
|||
|
523470/0 |
P100E |
Valve fuel pressure control, leakage. |
Reduced engine power. |
Check the component. |
|
523470/7 |
P1010 |
Valve fuel pressure control, does not open. |
Reduced engine power. |
Check the component. |
|
523470/11 |
P100F |
Valve fuel pressure control, fuel pressure too high. |
Reduced engine power. |
Check the component. |
|
523500/12 |
UC001 |
Communication error, CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
523550/2 |
P0607 |
|||
|
523600/12 |
P0607 |
Internal error engine control unit. |
No limitation. |
Contact Yuchai service. |
|
523601/3 |
P0699 |
Voltage feed 3 sensor, short circuit to voltage. |
Reduced engine power. |
Check the cable harness at the control unit. |
|
523601/4 |
P0698 |
Voltage feed 3 sensor, short circuit to ground. |
The engine takes longer to start than normal. The engine is running normally once it has started. |
Check the cable harness at the control unit. |
|
523604/12 |
UD1102 |
Communication error, CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
|
523605/11 |
UD1104 |
|||
|
523605/12 |
UD1105 |
|||
|
523606/11 |
UD1106 |
|||
|
523606/12 |
UD1107 |
|||
|
523607/11 |
UD1108 |
|||
|
523608/11 |
UD110A |
|||
|
523608/12 |
UD110B |
|||
|
523612/3 |
P1607 |
Internal error engine control unit. |
No limitation. |
Contact Yuchai service. |
|
523612/4 |
P1608 |
Internal error engine control unit. |
||
|
523613/2 |
P1014 |
Unreasonable fuel pressure. |
Reduced engine power. |
Check the cable harness between control unit and sensor. Check the sensor. |
|
523613/3 |
P0088 |
Fuel pressure too high. |
Reduced engine power. |
Check the fuel pressure. Check the fuel pump. Check the sensor. |
|
523613/4 |
P0087 |
Fuel pressure too low. |
Reduced engine power. |
Check the fuel pressure. Check the fuel pump. Check the sensor. |
|
523613/5 |
P1019 |
Fuel pressure too high. |
Reduced engine power. |
Check the fuel pressure. Check the fuel pump. Check the sensor. |
|
523613/7 |
P1018 |
Fuel pressure too low. |
Reduced engine power. |
Check the fuel pressure. Check the fuel pump. Check the sensor. |
|
523613/15 |
P1012 |
Fuel pressure too high. |
Reduced engine power. |
Check the fuel pressure. Check the fuel pump. Check the fuel filters. Check the sensor. |
|
523613/16 |
P1011 |
Fuel pressure too high. |
Reduced engine power. |
Check the component. |
|
523613/17 |
P1013 |
Fuel pressure too low. |
Reduced engine power. |
Check the fuel pressure. Check the fuel pump. Check the fuel filters. Check the sensor. |
|
523613/18 |
P101A |
Fuel pressure too high. |
Reduced engine power. |
Check the fuel pressure. Check the fuel pump. Check the fuel filters. Check the sensor. |
|
523615/2 |
P0252 |
Fuel metering valve, overheated power stage. |
No limitation. |
Check the cable harness at the control unit. |
|
523615/3 |
P0254 |
Valve fuel metering, short circuit to voltage. |
No limitation. |
Check the cable harness at the control unit. |
|
523615/4 |
P0253 |
Valve fuel metering, short circuit to ground. |
No limitation. |
Check the cable harness at the control unit. |
|
523615/5 |
P0251 |
Valve fuel metering, open circuit. |
No limitation. |
Check the cable harness at the control unit. |
|
523615/16 |
P025C |
Fuel metering valve, status signal too low. |
No limitation. |
Check the cable harness at the control unit. |
|
523615/18 |
P025D |
Fuel metering valve, status signal too high. |
No limitation. |
Check the cable harness at the control unit. |
|
523617/11 |
P060A |
Communication error, CAN bus. |
No limitation. |
Use diagnostic menu to check communication. Check the cable harness between Control unit, cab (D790-1) and Control unit, engine (D794). |
Error codes engine (engine alternative CumminsQSM11)
|
Code |
J1587 |
Description |
Limitation |
Action |
|
84/2 |
PID084/2 |
Electrical error, speed sensor, invalid data. |
Engine speed limited to maximum speed without gear. |
Check the cable harness between control unit and component. Check the sensor. |
|
84/10 |
PID084/10 |
Electrical error, speed sensor, signal manipulation detected. |
Engine speed limited to maximum speed without gear. |
Check the cable harness between control unit and component. Check the sensor. |
|
91/3 |
PID091/3 |
Electrical error, accelerator pedal, cable short circuit to voltage. |
The engine does not respond to throttle application.
|
Check the cable harness between control unit and component. Check the component. |
|
91/4 |
PID091/4 |
Electrical error, accelerator pedal, cable short circuit to ground. |
The engine does not respond to throttle application. |
Check the cable harness between control unit and component. Check the component. |
|
91/8 |
PID091/8 |
Electrical error, accelerator pedal, frequency too low. |
The engine does not respond to throttle application.
|
Check the cable harness between control unit and component. Check the component. |
|
91/8 |
PID091/8 |
Electrical error, accelerator pedal, frequency too high. |
The engine does not respond to throttle application. |
Check the cable harness between control unit and component. Check the component. |
|
91/19 |
SID091/2 |
Communication error with Control unit, cab (D790-1), electrical error, accelerator pedal. |
Engine only running at idle. |
Use diagnostic menu to find incorrect segment. |
|
97/3 |
PID097/3 |
Electrical error, water-in-fuel sensor, cable short circuit to voltage. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
97/4 |
PID097/4 |
Electrical error, water-in-fuel sensor, cable short circuit to ground. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
97/15 |
PID097/15 |
Water in fuel. |
Risk of white exhaust smoke and reduced engine output. |
Drain water from the fuel filter.
|
|
100/1 |
PID100/1 |
Low engine oil pressure. |
Engine output is reduced gradually. The engine is switched off after 30 seconds. |
Check the oil level in the engine; fill if necessary. |
|
100/2 |
PID100/2 |
Sensor, oil pressure, data error. |
No warning of low engine oil pressure. |
Check the sensor. |
|
100/3 |
PID100/3 |
Sensor oil pressure cable short-circuited to voltage. |
No warning of low engine oil pressure. |
Check the cable harness between control unit and component. Check the sensor. |
|
100/4 |
PID100/4 |
Sensor oil pressure, open circuit or short circuit to ground. |
No warning of low engine oil pressure. |
Check the cable harness between control unit and component. Check the sensor. |
|
100/18 |
PID100/1 |
Low engine oil pressure. |
No limitation. |
Check the oil level in the engine; fill if necessary. Check the sensor. |
|
102/2 |
PID102/2 |
Sensor boost pressure indicates high boost pressure, but other engine data indicates that pressure should be normal. |
Reduced engine power. |
Check the cable harness between control unit and component. Check the sensor. |
|
102/3 |
PID102/3 |
Sensor, boost pressure, cable short-circuited to voltage. |
Reduced engine power. |
Check the cable harness between control unit and component. Check the sensor.
|
|
102/4 |
PID102/4 |
Sensor boost pressure, cable short circuit to ground or open circuit. |
Reduced engine power. |
Check cable harness between control unit and component. Check the boost pressure sensor. |
|
103/16 |
PID103/0 |
Over-rev protection, turbo. |
Reduced engine power. |
Check the component. |
|
105/0 |
PID105/0 |
Intake air too hot. |
Engine output is reduced gradually. The engine is switched off after 30 seconds. |
Check the coolant level in the engine; fill if necessary. Check that the charge air cooler is clean, clean if necessary. Check that the fan belts are intact. Check the intake air temperature sensor. |
|
105/3 |
PID105/3 |
Sensor charge air temperature, cable short-circuited to voltage or open circuit. |
Risk of white exhaust smoke. No warning of high coolant temperature. |
Check cable harness between control unit and component. Check that the charge air temperature sensor is correctly installed and connected. Check the charge air temperature sensor. |
|
100/3 |
PID100/3 |
Sensor oil pressure cable short-circuited to voltage. |
No warning of low engine oil pressure. |
Check the cable harness between control unit and component. Check the sensor. |
|
100/4 |
PID100/4 |
Sensor oil pressure, open circuit or short circuit to ground. |
No warning of low engine oil pressure. |
Check the cable harness between control unit and component. Check the sensor. |
|
100/18 |
PID100/1 |
Low engine oil pressure. |
No limitation. |
Check the oil level in the engine; fill if necessary. Check the sensor. |
|
102/2 |
PID102/2 |
Sensor boost pressure indicates high boost pressure, but other engine data indicates that pressure should be normal. |
Reduced engine power. |
Check the cable harness between control unit and component. Check the sensor. |
|
102/3 |
PID102/3 |
Sensor, boost pressure, cable short-circuited to voltage. |
Reduced engine power. |
Check the cable harness between control unit and component. Check the sensor.
|
|
102/4 |
PID102/4 |
Sensor boost pressure, cable short circuit to ground or open circuit. |
Reduced engine power. |
Check cable harness between control unit and component. Check the boost pressure sensor. |
|
103/16 |
PID103/0 |
Over-rev protection, turbo. |
Reduced engine power. |
Check the component. |
|
105/0 |
PID105/0 |
Intake air too hot. |
Engine output is reduced gradually. The engine is switched off after 30 seconds. |
Check the coolant level in the engine; fill if necessary. Check that the charge air cooler is clean, clean if necessary. Check that the fan belts are intact. Check the intake air temperature sensor. |
|
105/3 |
PID105/3 |
Sensor charge air temperature, cable short-circuited to voltage or open circuit. |
Risk of white exhaust smoke. No warning of high coolant temperature. |
Check cable harness between control unit and component. Check that the charge air temperature sensor is correctly installed and connected. Check the charge air temperature sensor. |
|
Code |
J1587 |
Description |
Limitation |
Action |
|
105/4 |
PID105/4 |
Sensor charge air temperature, cable short circuit to ground or open circuit. |
Risk of white exhaust smoke. No warning of high coolant temperature. |
Check the cable harness between control unit and component. Check that the sensor is correctly installed and connected. Check the sensor. |
|
108/2 |
PID108/2 |
Electrical error, air pressure sensor, data error. |
Reduced engine power. |
Check the sensor. |
|
108/3 |
PID108/3 |
Electrical error, air pressure sensor, cable short circuit to voltage. |
Reduced engine power.
|
Check the cable harness between control unit and component. Check the sensor. |
|
108/4 |
PID108/4 |
Electrical error, air pressure sensor, cable short circuit to ground. |
Reduced engine power. |
Check the cable harness between control unit and component. Check the sensor. |
|
110/0 |
PID110/0 |
High coolant temperature. |
Engine output is reduced gradually. The engine is switched off after 30 seconds. |
Check the coolant level. Check that radiator is clean. Check if there is air in coolant system. Check the cap on the expansion tank. Check the sensor. Check the thermostat. |
|
110/3 |
PID110/3 |
Sensor coolant temperature, cable short-circuited to voltage or open circuit. |
No indication of engine temperature.
|
Check the cable harness between control unit and component. |
|
110/4 |
PID110/4 |
Sensor coolant temperature, cable short circuit to ground. |
No indication of engine temperature.
|
Check the cable harness between control unit and component. Check that the sensor is connected correctly. Check the sensor. |
|
111/1 |
PID111/1 |
Low coolant level. |
Engine output is reduced gradually. The engine is switched off after 30 seconds. |
Check the coolant level; fill if necessary. Check the sensor. |
|
111/2 |
PID111/2 |
Electrical error, sensor coolant level, data error. |
No warning of low coolant level. |
Check the cable harness between control unit and component. Check the sensor. |
|
166/2 |
PID116/2 |
Output imbalance between cylinders. |
Rough idle. |
Check the fuel quality. The error code could be generated if the fuel system has been opened, allowing air to enter the system. Troubleshoot the engine. |
|
167/1 |
PID167/1 |
Low battery voltage. |
Warning active until voltage is correct. |
Check batteries and alternator. |
|
167/16 |
PID167/0 |
Low battery voltage. |
Warning active until voltage is correct. |
Check fuses. Check batteries and alternator.
|
|
167/18 |
PID167/1 |
High battery voltage. |
Warning active until voltage is correct. The engine runs at raised idle in order to increase voltage. |
Check batteries and alternator. |
|
168/16 |
PID168/0 |
High voltage feed to control unit. |
No limitation. |
Check fuses. Check batteries and alternator. |
|
168/18 |
PID168/1 |
Low voltage feed to control unit. |
Rough idle. |
Check fuses. Check batteries and alternator. |
|
175/0 |
PID175/0 |
High engine oil temperature. |
Engine output is reduced gradually. The engine is switched off after 30 seconds. |
Check the coolant and oil level in the engine; fill if necessary. Check that the oil cooler is clean, clean if necessary. Check that the fan belts are intact. Check the sensor. |
|
175/3 |
PID175/3 |
Sensor, oil temperature, cable short-circuited to voltage or open circuit. |
No indication of engine oil temperature. |
Check the cable harness between control unit and component. Check that the sensor is connected correctly. |
|
175/4 |
PID175/4 |
Sensor oil temperature, cable short circuit to ground. |
No indication of engine oil temperature. |
Check the cable harness between control unit and component. Check the sensor. |
|
188/4 |
SID032/4 |
Electrical error, wastegate solenoid valve 1 short circuit to ground. |
Reduced engine power. |
Check the cable harness between control unit and component. Check the solenoid valve. |
|
190/0 |
PID190/0 |
Engine speed too high. |
Fuel supply restricted until engine speed is below permitted value. |
Ease off the throttle or select higher gear. |
|
190/2 |
PID190/2 |
Electrical error, sensor rotation speed/ignition mode; no signal from any sensors. |
The engine stops and cannot be restarted. |
Check the cable harness between control unit and component. Check the sensor. |
|
190/10 |
PID190/10 |
Electrical error, sensor rotation speed/ignition mode, one of two signals missing. |
No limitation. |
Check the cable harness between control unit and component. Check the sensor. |
|
191/16 |
PID191/0 |
Speed limitation activated. |
Speed is reduced. |
Reduce throttle application. |
|
191/18 |
PID191/1 |
Speed warning for low speed. |
Engine only running at idle. |
Increase throttle application. |
|
251/2 |
PID251/2 |
Internal error Control unit, engine. |
- |
- |
|
441/3 |
PID441/3 |
Extra temperature sensor, short circuit to ground. |
No warning of high temperature, Control unit, engine (D794). |
Check the cable harness between control unit and component. Check the sensor. |
|
441/4 |
PID441/4 |
Extra temperature sensor, short circuit to voltage. |
No warning of high temperature, Control unit, engine (D794). |
Check the cable harness between control unit and component. Check the sensor. |
|
558/2 |
SID230/2 |
Electrical error, sensor accelerator pedal, idle contact, data error. |
No limitation. |
Check cable between control unit and component. Check component. |
|
558/4 |
SID230/4 |
Electrical error, sensor accelerator pedal, idle contact, cable short circuit to ground. |
The engine does not respond to throttle application. |
Check cable between control unit and component. Check component. |
|
558/13 |
SID230/1 3 |
Electrical error, sensor accelerator pedal, idle contact, calibration error. |
Engine only running at idle. |
Check cable between control unit and component. Check component. |
|
608/2 |
SID250/2 |
Communication error with Control unit, engine (D794). |
No limitation.
|
Check the control unit. |
|
608/9 |
SID250/9 |
Communication error with Control unit, engine (D794). |
No limitation. |
Check the control unit. |
|
620/3 1080/3 |
SID232/3 |
Electrical error, reference voltage to sensor short circuit to voltage. |
Reduced engine power. No warning of low oil pressure or low coolant level.
|
Check the cable harness between control unit and component. Check the control unit. |
|
620/4 1081/4 |
SID232/4 |
Electrical error, reference voltage to sensor short circuit to ground. |
Reduced engine power. No warning of low oil pressure or low coolant level.
|
Check the cable harness between control unit and component. Check the component.
|
|
626/11 |
SID237/1 1 |
Electrical error to control of relay preheating. |
Preheating not working. Risk of white smoke. |
Check the cable harness between control unit and component. Check the component. |
|
627/2 |
SID251/2 |
Voltage feed to control unit disappears but ignition not off. |
Reduced engine power. Engine difficult to start or dies.
|
Check fuses. Check batteries and alternator. |
|
629/12 |
SID254/1 2 |
Internal error Control unit, engine. |
The engine does not start. |
Check the control unit. |
|
Code |
J1587 |
Description |
Limitation |
Action |
|
629/12 |
SID254/1 2 |
Internal error Control unit, engine. |
No limitation. |
Check the control unit. |
|
630/2 |
SID253/2 |
Software error Control unit, engine (D794). |
Reduced engine power. Engine difficult to start or dies. |
Reprogram the software in Control unit, engine (D794). |
|
632/3 |
SID017/3 |
Electrical error, fuel cut-off solenoid valve, cable short circuit to voltage. |
No limitation.
|
Check the cable harness between control unit and component. Check the solenoid valve. |
|
632/4 |
SID017/4 |
Electrical error, fuel cut-off solenoid valve, cable short circuit to ground. |
The engine is switched off. |
Check the cable harness between control unit and component. Check the solenoid valve. |
|
639/2 |
SID231/2 |
Communication error with Control unit, engine (D794). |
Functions via CAN bus not working. |
Use diagnostic menu to find incorrect segment. |
|
639/9 |
SID231/9 |
Communication error with Control unit, engine (D794). |
Functions via CAN bus not working. |
Use diagnostic menu to find incorrect segment. |
|
639/9 |
SID231/9 |
Communication error with Control unit, engine (D794), timeout error. |
Functions via CAN bus not working. |
Use diagnostic menu to find incorrect segment. |
|
639/13 |
SID231/1 3 |
Communication error with Control unit, engine (D794), configuration error. |
Functions via CAN bus not working. |
Use diagnostic menu to find incorrect segment. |
|
644/2 |
SID030/2 |
Electrical error, accelerator pedal, signal not within valid interval. |
The engine is switched off. |
Check the cable harness between control unit and component. Check the component. |
|
647/4 |
SID033/4 |
Electrical error, fan connection, cable short circuit to ground. |
Cooling fan runs constantly. |
Check the cable harness between control unit and component. Check the component. |
|
651/5 |
SID001/5 |
Electrical error, injector cylinder 1, open circuit on cable. |
Engine only runs on 5 cylinders, sounds rough and has reduced power. |
Check the cable harness between control unit and component. Check the component. |
|
651/6 |
SID001/7 |
Electrical error, injector cylinder 1, cable short circuit to ground. |
Engine only runs on 5 cylinders, sounds rough and has reduced power. |
Check the cable harness between control unit and component. Check the injector. |
|
652/5 |
SID002/5 |
Electrical error, injector cylinder 2, open circuit on cable. |
Engine only runs on 5 cylinders, sounds rough and has reduced power. |
Check the cable harness between control unit and component. Check the injector. |
|
Code |
J1587 |
Description |
Limitation |
Action |
|
652/6 |
SID002/6 |
Electrical error, injector cylinder 2, cable short circuit to ground. |
Engine only runs on 5 cylinders, sounds rough and has reduced power. |
Check the cable harness between control unit and component. Check the injector. |
|
653/5 |
SID003/5 |
Electrical error, injector cylinder 3, open circuit on cable. |
Engine only runs on 5 cylinders, sounds rough and has reduced power. |
Check the cable harness between control unit and component. Check the injector. |
|
653/6 |
SID003/6 |
Electrical error, injector cylinder 3, cable short circuit to ground. |
Engine only runs on 5 cylinders, sounds rough and has reduced power. |
Check cable between control unit and component. Check component.
|
|
654/5 |
SID004/5 |
Electrical error, injector cylinder 4, open circuit on cable. |
Engine only runs on 5 cylinders, sounds rough and has reduced power. |
Check the cable harness between control unit and component. Check the injector. |
|
654/6 |
SID004/6 |
Electrical error, injector cylinder 4, cable short circuit to ground. |
Engine only runs on 5 cylinders, sounds rough and has reduced power. |
Check the cable harness between control unit and component. Check the injector. |
|
655/5 |
SID005/5 |
Electrical error, injector cylinder 5, open circuit on cable. |
Engine only runs on 5 cylinders, sounds rough and has reduced power. |
Check the cable harness between control unit and component. Check the injector. |
|
655/6 |
SID005/6 |
Electrical error, injector cylinder 5, cable short circuit to ground. |
Engine only runs on 5 cylinders, sounds rough and has reduced power. |
Check cable between control unit and component. Check component. |
|
656/5 |
SID006/5 |
Electrical error, injector cylinder 6, open circuit on cable. |
Engine only runs on 5 cylinders, sounds rough and has reduced power. |
Check cable between control unit and component. Check component. |
|
656/6 |
SID006/6 |
Electrical error, injector cylinder 6, cable short circuit to ground. |
Engine only runs on 5 cylinders, sounds rough and has reduced power. |
Check the cable harness between control unit and component. Check the injector. |
|
702/3 |
SID040/3 PID154/3 |
Electrical error, auxiliary output 2, cable short circuit to voltage. |
No limitation.
|
Check the cable harness between control unit and component. Check the component. |
|
703/3 |
SID051/3 |
Electrical error, auxiliary output 2, cable short circuit to voltage. |
No limitation. |
Check the cable harness between control unit and component. Check the component. |
|
974/3 |
SID029/3 |
Electrical error, extra accelerator pedal, cable short circuit to voltage. |
The engine does not respond to throttle application. |
Check the cable harness between control unit and component. Check the component. |
|
974/4 |
SID029/4 |
Electrical error, extra accelerator pedal, cable short circuit to ground. |
The engine does not respond to throttle application. |
Check the cable harness between control unit and component. Check the component. |
|
974/19 |
SID029/2 |
Communication error with Control unit, cab (D790-1), electrical error, accelerator pedal. |
The engine does not respond to throttle application. |
Use diagnostic menu to find incorrect segment. |
|
1043/3 |
PID221/3 |
Electrical error, accelerator pedal reference voltage, cable short circuit to voltage. |
Engine only running at idle. |
Check the cable harness between control unit and component. Check the component. |
|
1043/4 |
PID221/4 |
Electrical error, accelerator pedal reference voltage, cable short circuit to ground. |
Engine only running at idle. |
Check the cable harness between control unit and component. Check the component. |
|
1072/11 |
SID070/11 |
Electrical error, solenoid valve engine brake 2. |
Engine brake 1 cannot be activated. |
Check the cable harness between control unit and component. Check the solenoid valve. |
|
1073/11 |
SID029/11 |
Electrical error, solenoid valve engine brake 2. |
Engine brake 2 cannot be activated. |
Check the cable harness between control unit and component. Check the solenoid valve. |
|
1079/3 |
SID232/3 |
Electrical error, reference voltage to sensor short circuit to voltage. |
Reduced engine power. |
Check the cable harness between control unit and component. Check the sensor. |
|
1079/4 |
SID232/4 |
Electrical error, reference voltage to sensor short circuit to ground. |
Reduced engine power. |
Check the cable harness between control unit and component. Check the sensor. |
|
1188/3 |
SID032/3 |
Electrical error, solenoid valve wastegate 1 short circuit to voltage. |
Reduced engine power. |
Check the cable harness between control unit and component. Check the solenoid valve. |
|
1189/3 |
SID088/3 |
Electrical error, solenoid valve wastegate 2 short circuit to voltage. |
Reduced engine power. |
Check the cable harness between control unit and component. Check the solenoid valve. |
|
1189/4 |
SID88/4 |
Electrical error, wastegate solenoid valve 2 short circuit to ground. |
Reduced engine power. |
Check the cable harness between control unit and component. Check the solenoid valve. |
|
1265/4 |
SID085/4 |
Electrical error, oil-burn solenoid valve, cable short circuit to ground. |
No limitation. |
Check the cable harness between control unit and component. Check the solenoid valve. |
|
1319/2 |
PID102/2 |
Electrical error, boost pressure sensor. |
Reduced engine power. |
Check the cable harness between control unit and component. Check the sensor. |
|
1380/1 |
PID017/1 |
Low oil level engine. |
No limitation. |
Check the oil level in the engine; fill if necessary. |
|
1383/31 |
SID151/1 1 |
Engine switched off other than with start key, causing load. |
No limitation. |
Switch of the engine with the start key. |
|
1384/31 |
SID029/1 4 |
Engine switched off other than with start key, causing load. |
No limitation. |
Switch of the engine with the start key.
|
|
1387/3 |
PID223/3 |
Electrical error, extra pressure sensor, cable short circuit to voltage. |
No pressure guard (customer-specific option). |
Check the cable harness between control unit and component. Check the sensor. |
|
1387/4 |
PID223/4 |
Electrical error, extra pressure sensor, cable short circuit to ground. |
No pressure guard (customer-specific option). |
Check the cable harness between control unit and component. Check the sensor. |
|
1484/31 |
SID216/1 1 |
Error codes in other control units. |
No limitation. |
Check error codes for other machine control units, particularly the Control unit, cab (D790-1) and Control unit, transmission (D793). |
linz (Wednesday, 25 October 2023 14:44)
error code 22/00 on te32 transmission of a kalmar drt 450.need help to fix it.
