001 short to ground left front direction indicator

002 open left front direction indicator

003 short to ground right front direction indicator

004 open right front direction indicator

005 short to ground left rear direction indicator

006 open left rear direction indicator

007 short to ground right rear direction indicator

008 open right rear direction indicator

009 short to ground lamp high beam left front

010 open left front high beam lamp

011 short to ground lamp high beam right front

012 open high beam lamp right front

013 short to ground lamp

014 open back lamp left rear

015 short to ground reverse lamp right rear

016 open back lamp right rear

017 short to ground lamp brake signal left rear

018 open left rear brake signal lamp

019 short to ground of the brake signal lamp right rear

020 open brake signal lamp right rear

021 short to ground side marker light

022 open side marker light

023 short to ground left turn signal

024 open left direction indicator

025 short to ground right direction indicator

026 open right direction indicator

101 short to ground in the lighting lamp in the cab

102 breakage of the left lighting lamp in the cab

103 short to ground of the right lighting lamp in the cab

104 breakage of the right lighting lamp in the cab

105 short to ground of the left door open indicator

106 open left door indicator open

107 short to ground indicator open right door

108 open right door indicator open

109 short to ground lamp dipped beam left front

110 open left front low beam lamp

111 short to ground lamp dipped beam right front

112 open low beam lamp right front

113 short to ground of the left lamp of illumination of numbers

114 open left room light

115 short to ground of the right lamp of illumination of numbers

116 breakage of the right lamp of illumination of numbers

117 short to ground fog lamp left rear

118 open left rear fog lamp

119 short to ground fog lamp right rear

120 open right rear fog lamp

121 short to ground left power window motor

122 open left power window motor

123 short to ground power window motor right

124 open power window motor right

125 short to ground motor left rearview mirror

126 open engine left rear mirror

127 short to ground motor of the right rear-view mirror

128 open engine of the right rear-view mirror

129 short to ground washer pump motor

130 open washer pump motor

131 short to ground wiper motor

132 open wiper motor

133 short to ground of the left footrest light bulb

134 open left light bulb footrest

135 short to ground of the right footrest light bulb

136 open right footrest light bulb

137 short to ground fog lamp left front

138 open left front fog lamp

139 short to ground fog lamp

140 open front fog lamp right

141 short to ground left-hand side light

142 open left side marker light

143 short to ground side light right turn

144 open side marker light of the right turn

145 short to ground in a chain of the left lock

146 open circuit in the left lock chain

147 short to ground in the right lock circuit

148 open in the chain of the right lock

149 short to ground speed indicator 1

150 open speed indicator 1

151 short to ground speed indicator 2

152 open speed indicator 2

153 short to ground speed indicator 3

154 open speed indicator 3

155 short to ground horn

156 horn break

157 short to ground air throat

158 open air filler

159 short to ground of the differential lock solenoid valve between the axles

160 open differential lock solenoid valve between the axles

161 short to ground positioning lamp left front

162 open positioning lamp left front

163 short to ground positioning lamp right front

165 short to ground for the upper side light in the lighting lamp assembly in

166 breakage of the upper marker lamp in the lighting lamp assembly in the cab

167 short to ground in the CAN line

168 open in the CAN line

169 short to ground left mirror heating

170 open left mirror heating

171 short to ground right mirror heating

172 open right mirror heating

173 short to ground wiper position signal

174 open in the wiper position signal circuit

175 short to ground solenoid valve interwheel differential lock

176 open interwheel differential lock solenoid valve

177 Power supply overvoltage Master

178 Master supply undervoltage

201 wire breakage of the lighting lamp in the cab

202 open wire left front lighting lamp

203 open wire right front lighting lamp

204 open wire in the rear headlight assembly

205 open circuit in the backup node

206 open in the left door assembly

207 open in the assembly of the right door

208 open in the trailer assembly

209 Malfunction in the control of the signal "On"

210 Malfunction in the control of the signal "ST"

211 Malfunction in the control signal "ACC"

212 sticking of light switches in the cockpit on the dashboard

213 sticking washer switch

214 sticking own switch of the left lighting lamp in the cab

215 sticking own switch of the left lighting lamp in the cab

216 sticking of its own switch of the alarm lamp of an open door

217 sticking upper left door window switch

218 Bottom sticking of the left door window switch

219 Upper sticking of the right door window switch on the driver's side

220 Lower sticking of the right door window switch on the driver's side

221 Upper sticking of the right door window switch on the co-driver's side

222 Lower sticking of the right door window switch on the co-driver's side

223 Upper sticking rearview mirror switch

224 Bottom sticking rearview mirror switch

225 Left sticking rearview mirror switch

226 Right sticking rear mirror switch

227 sticking of the frost removal switch

228 sticking horn switch

229 Discrepancy between the speed ratio of devices and this indicator Master \

241 short to ground left trailer turn signal

242 open left trailer turn signal

243 short to ground of the right turn signal of the trailer

244 open right trailer turn signal

245 short to ground of the trailer brake signal lamp

246 open trailer brake signal lamp

247 short to ground fog lamp trailer

248 open trailer fog lamp

249 short to ground for the trailer reverse lamp

250 open trailer reversing lamp

251 short to ground small trailer light

252 open small trailer light

253 short to ground of the left expansion direction indicator of the trailer

254 open expansion left trailer turn signal

255 short to ground of the expansion right indicator of the dimensions of the trailer

256 breakage of the expansion right indicator of the dimensions of the trailer

257 short to ground of the working headlight of the trailer

258 open working trailer headlight

1 General electrical fault

2 General signal error

3 Frequency modulated / pulse modulated signal error

4 Internal system error

5 System programming error

6 Algorithm error

7 Mechanical failure

8 Data bus signal / message error

9 Component error

11 Short to ground

12 Short circuit to +

13 Open circuit

14 Open circuit / short to ground

15 Open circuit / short circuit to +

16 The voltage in the circuit is below the required

17 The voltage in the circuit is higher than the required

18 The current in the circuit is below the required

19 The current in the circuit is higher than the required

21 Signal amplitude below minimum

22 Signal amplitude above maximum

23 Signal - permanently low

24 Signal - constantly high

25 Waveform error

26 Signal change rate below required

27 Signal change rate higher than required

28 Signal offset value out of range / zero adjustment error

29 Invalid signal

31 No signal

32 Low signal level - the period is less than the minimum allowable

33 Low signal level - the period is longer than the maximum allowable

34 High signal level - the period is less than the minimum allowable

35 High signal level - the period is longer than the maximum allowable

36 Signal frequency too low

37 Signal frequency too high

38 Signal frequency - incorrect

39 Signal - too few pulses

41 General checksum error

42 General memory error

43 General memory error

44 Data memory error

45 Program memory error

46 Calibration / parameter memory error

47 Error microcontroller security system

48 Control software error

49 Internal electronic error

51 Component not programmed

52 Component program not activated

53 Component program disabled

54 Loss of calibration

55 System not configured

56 Invalid / incompatible configuration

57 Invalid / incompatible software component

61 Signal calculation error

62 Signal comparison error

63 Circuit / component protection timeout

64 Signal plausibility error

65 Signal - too few switchings

66 Signal - too many switches

67 Incorrect signal after switching

68 Event information

71 Drive - seizure

72 Actuator - stuck open

73 Actuator - stuck closed

74 Drive - slippage

75 Emergency position cannot be reached

76 Incorrect installation position

77 Desired position could not be reached

78 Incorrect alignment or adjustment

79 Mechanical drive error

81 Invalid data sequence received

82 Cycle counter - value incorrect / not updated

83 Incorrect calculated value of the protective signal

84 Signal - below acceptable level

85 Signal - above the permissible level

86 Invalid signal

87 Skip message

88 Data bus disabled

91 Component parameter - out of range

92 Function / malfunction

93 Doesn't work

94 Unexpected component action

95 Incorrect assembly

96 Internal component error

97 Operation of a component or system is difficult or blocked

98 Overheating of a component or system

1A Resistance in the circuit below the required

1B Resistance in the circuit is higher than required

1C The voltage in the circuit is out of range

1D The current in the circuit is out of the specified range

1E Resistance in the circuit is out of range

1F Loose electrical circuit contact

2A Signal - constant level

2B Signal - cross

2F Signal - chaotic

3A Signal - too many pulses

4A Incorrectly installed component

4B Overheating condition

7A Fluid leaking or seal leaking

7B low working fluid level

8F Signal - chaotic

9A Component or system operating conditions
